Lutz

Air Drum Pumps, 19 GPM

Model: DB824

Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.

Sold as: Each

  • Max. Flow Rate: 19 GPM
  • Max. Head: 33'
  • Pump Tube Material: Polypropylene
  • Bearings: Carbon
  • Gravity: 1.6
  • Specific Viscosity cps: 850
  • Wt. lbs.: 11
  • MIXING DRUM PUMPS
  • Examples of Liquids: Chemical, pharmaceutical and metalworking industries, in food production, in printing works, car repair, workshops, painting/decorating. ; MIXING DRUM PUMPS: Mixing pump tube is to be used where it is necessary to mix and pump in a single operation. Ideal for use in containers or in drums with a 2" bunghole. Drive shaft of pump tube is sealed by a single-acting mechanical seal and two shaft seals. Pump tube must not be allowed to run dry. Comes with 39" pump tube and stainless steel drive shaft. NOTE: Only DB837and DB829can be used for flammable liquids and include static kit. ; A. Electric motor: 640 W, 0.85 HP, 120 V, 60 Hz, open drip-proof with 16' cord and plug ; ; Pumps that have a stainless steel construction come with a wall hanger, 10 ft. bonding wire and 26' grounding wires. ; Pumps that have a polypropylene construction come with a barrel adaptor, a wall hanger, 8' PVC hose and hose c-clamps (except DB827) .
